規格
工作頻率 (機械):
   120 Operation / mim
工作頻率 (電氣):
   10~30 Operation / mim
接觸電組:
   100m Ω(max)
絶緣電阻(at 500 VDC)
   100M Ω(Min)
機械壽命
   Min. 1000000 Operations
電氣壽命
   1A/3A-Min.10,000 Operations

額定值
0.1A/1A/3A 125VAC ; 1A/3A 250VAC; 1A 24VDC; 3A 12VDC

應用
1. Computer mouse
2. Joysticks
3. Charger unit for mobile phone
4. Detection of key position for automobiles
5. Small home appliances
6. Central heating control
7. Electronic Door Locks
8. Smart Meter
基本スイッチD2F
